Digital YOKOGAWA WT333E Power Analyzer

Name: Digital YOKOGAWA WT333E Power Analyzer
Brand: PRAM ELECTECH
Price: 475000 INR
Availability: InStock

Price 475000 INR/ Piece

Get a Price/Quote

Digital YOKOGAWA WT333E Power Analyzer Specification

Product Type
Power Analyzer

Material
Mild Steel

Measuring Voltage Range
440 Volt (v)

Operating Temperature
45 Celsius (oC)

Frequency (MHz)
50 Hertz (HZ)

Size
213 (W) x 177 (H) x 409 (D) mm

Dimension (L*W*H)
213 (W) x 177 (H) x 409 (D) mm Millimeter (mm)

Weight
6.5 Kilograms (kg)

Warranty
1 Year

Digital YOKOGAWA WT333E Power Analyzer Trade Information

Minimum Order Quantity
10 Number

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
10 Per Month

Delivery Time
18 Week

Packaging Details
wooden box

Main Export Market(s)
Asia

Main Domestic Market
All India

About Digital YOKOGAWA WT333E Power Analyzer

TheYokogawa WT333 Digital Power Meter provides a wide current input range, fastdisplay, and rapid data update rate in a compact and powerful instrument. Highperformance and reliable power measurement makes it the preferred power meterin numerous industries from production lines to R&D applications.

Thecompact, 3-phase power meters of the WT333E series have a basic accuracy of(0.1% of reading + 0.05% of RMS range) and are ideal for precise measurementof power consumption of electrical devices, as well as for energy efficiencyand energy saving studies. The lowest currents, for example, can be measuredfrom 50 A with specified accuracy.

Model : WT333E-C2-B/G5

Specification:
Simultaneous harmonicanalysis with high bandwidth.
Automatic adjustment of the data update rate.
Automatic range switching for integrating measurements.
Basic accuracy for power measurements (50/60 Hz): (0.1% of the measuredvalue + 0.05% of the effective value measuring range).
Frequency bandwidth: DC, 0.1 Hz...100 kHz.
Current measurement range direct input: 6 measuring ranges/0.5...20 A.
RMS voltage ranges: 6 measuring ranges/15...600 V.
External sensor input EX1: 2.5/5/10 V; EX2: 50/100/200/500 mV/1/2 V.
Signals with crest factors up to 300 measurable in all ranges.
Simultaneous measurement of RMS, MEAN, and DC voltage.
Frequency measurement: 2 channels (voltage and current).
4x 7-segment LED displays
Sampling rate 100 kS/s (16 bit).
Data update rate 100/250/500 ms/1/2/5/10/20 s, Auto.
Harmonics analysis incl. THD calculation up to the 50th order available
Automatic range setting in integration mode.
Comparator function.
Interfaces: USB and RS232
Free PC application software WT ViewerEfree for parameterization, control anddata acquisition included in the scope of delivery
